BRAVO 40 MPPT Solar Charge Controller — Reliable 40A Power for 12V/24V Solar Systems
The BRAVO 40 MPPT Solar Charge Controller delivers premium performance with up to 40 amps of charging power, making it a top pick for reliable off-grid solar power management. Designed for both 12V and 24V battery banks, this smart MPPT (Maximum Power Point Tracking) controller achieves a tracking efficiency above 99.5% and conversion efficiency up to 98%. Ideal for cabins, RVs, and backup systems, the BRAVO 40 ensures your solar energy system charges efficiently and safely. Available now from Generation Eco Store, your trusted retailer for the best solar gear of 2025.
Highlights of the BRAVO 40 MPPT Controller
- Advanced MPPT charging algorithm with tracking efficiency over 99.5%
- Up to 98% charge conversion efficiency for maximum solar harvesting
- Automatically supports 12V and 24V DC systems
- Extensive battery support: AGM, GEL, Wet, Crystal, Calcium, LFP, LTO, and LCO
- Reverse discharge, overvoltage, and internal electronic protections
- Conformal-coated PCBA for long-lasting durability and weather resistance
- Built with premium safety protections and UL1741/EN62109 compliance
- Ideal for off-grid solar, cabins, RVs, or backup battery systems
Specifications
| Spec | Details |
|---|---|
| System Nominal Voltage | 12V / 24V Auto Recognition |
| Max. PV Open Circuit Voltage | 100V |
| Max Charging Current | 40A |
| Recommended PV Input | 600W (12V) / 1200W (24V) |
| Compatible Batteries | AGM, GEL, Wet, Crystal, Calcium / LFP, LTO, LCO |
| IP Rating | IP43 (Inside PCBA), IP22 (Connections) |
| Dimensions | 7.7 x 5.5 x 2.9 in (195 x 142 x 74 mm) |
| Weight | 2.58 lbs (1.17 kg) |
Specifications & Dimension
Charge Controller
System Voltage: 12V / 24V Auto Recognition
Max PV Open Circuit Voltage: 100V
Max Charging Current: 40A
Recommended PV Input: 600W (12V) / 1200W (24V)
Compatible Batteries: AGM, GEL, Wet, Crystal, Calcium / LFP, LTO, LCO
IP Rating: IP43 (PCB), IP22 (Connections)
Dimensions: 7.7 x 5.5 x 2.9 in
Weight: 2.58 lbs (1.17 kg)
What's in the Box?
- 1x BRAVO 40 MPPT Solar Charge Controller
- 1x User Manual
- Mounting Hardware (Screws and Brackets)
- Warranty Card
Guides & More
Shipping Policy
- Free & Fast Shipping
We offer free shipping on most Rich Solar Charge Controllers orders across the lower 48 states, using the most reliable freight partners. Orders typically ship within 5 business days, with tracking provided within 24 hours of dispatch. - Tracking & Delivery Scheduling
You’ll receive an order confirmation email immediately after placing your order. Tracking details are usually shared within 3–5 business days. Please review your shipping address carefully—corrections after shipment may incur a fee. - Important Shipping Notes
Ensure your location can accommodate freight deliveries. Additional charges may apply for access-restricted areas, remote locations, or deliveries requiring special transport (e.g., ferry or plane).
See our full Shipping Policy here
Return Policy
- Hassle-Free Returns
We offer a 30-day return window from the date you receive your item. Items must be unused, in original packaging, and accompanied by proof of purchase. Some items may incur a 15–25% restocking fee, especially larger freight-shipped products. Cancellations made before shipping will incur a 3-5% processing fee. - Damaged or Special Orders
Please report any damages within 24 hours of delivery. Installed or opened items may not be returnable. Select brands such as Victron and Pytes may be non-returnable based on manufacturer policies.
See our full Return Policy here
What Sets it Apart
-
Advanced MPPT Tracking
-
Enjoy tracking efficiency above 99.5% and a charge conversion efficiency up to 98% for top-tier solar charging.
-
Full Battery Compatibility
-
Supports multiple battery types including Gel, AGM, WET, Crystal, Calcium, LiFePO4, LTO, and LCO.
-
Built for Real-World Durability
-
Designed to UL1741 and EN/IEC 62109-1 standards with conformal coating for extra environmental protection.
See it in Action
Have a Question? We Have Answers
What size solar panel array can I use with the Bravo 40?
-
The Bravo 40 supports up to 600W on 12V systems and 1200W on 24V systems. The total panel open-circuit voltage must stay under 100V.
Can the Bravo 40 MPPT charge controller be used with lithium batteries?
-
Yes, it supports LiFePO4, LTO, and LCO batteries, along with traditional Gel, AGM, WET, Crystal, and Calcium batteries.
Does the Bravo 40 support 12V and 24V systems automatically?
-
Yes, it features auto-detection for 12V and 24V systems — no manual setup required.
What is the warranty on Charge Controllers?
Warranty for product varies based on the brand and the product. For some of the warranties, https://generationecostore.com/pages/warranty view OEM warranty policy. For any questions, please reach out to us at hello@generationecostore.com
Can I return the Charge Controllers if I'm not satisfied?
We offer a 30-day return window from the date you receive your item. To be eligible for a return, the item must be unused, in its original packaging, and include proof of purchase.
